Key Features
Features and Functions
- Able to be connected with a tripod by a 5/8” tread
- Projects two laser beams, up and down.
- Simple and easy to use
- Sealed and dustproof
- Used in construction , deformation observation
Package Details
- 2 x AA Batteries
- Hard carry case
- Manual
- Target
Specifications
- Accuracy; 1/45000
- Effective aperture; 30mm
- Magnification; 25X
- Field of view; 1°30’
- Minimum focus distance; 0.5m
- Wavelength; 635nm
- Laser class; Class IIIA
- Minimum viewing distance; 0.5m
- Plummet accuracy; 0.5mm/1.5mm
- Day; 150m
- Night; 500m
- 40m range; maximum 4mm
- 100m range; maximum 5mm
- Deviation optical and laser axis; ≤ 2”
- Mean square plumb error; ≤ 5”
- Operating temperature; -10°C ~+ 40°C
- Net weight; 2.8kg
- Power supply; 2 “AA” batteries
